L404F1227 PRESSOSTATO 0,7-10 BAR-1

SKU: L404F1227 Categories: ,

L404F1227 PRESSOSTATO 0,7-10 BAR-1

CONTATTACI PER RICHIEDERE IL PREZZO
Description

L404F1227 PRESSOSTATO 0,7-10 BAR-1 contatto SPDT –

  • Application:Provide control of steam, air, non-combustible gases or non-corrosive fluids
  • Operating Range: 1 to 8 psi
  • Mounting:1/4 in. NPT internal thread or surface mount through back of case
  • Switch Operation:Auto recycle
  • Switching Action:SPDT snap action, make R-W, break R-B on pressure rise
  • Sensor Element:Stainless Steel diaphragm
  • Pipe Connections, Main or High Pressure:1/4″ NPT internal thread
  • Switch Contact Ratings (120v):8.0 AFL, 48.0 ALR, 10.0 A resistive
  • Switch Contact Ratings (240v): 5.1 AFL, 30.6 ALR, 5.0 A resistive
  • Maximum Sustained Operating Pressure: 25 psi
  • Pressure Differential (psi): 2 to 6 psi
  • Differential Type: Subtractive
  • Temperature Range: -35 to 150 F
  • Electrical Connections:Screw terminals

DESCRIZIONE PRODOTTO

L404F1227 PRESSOSTATO 0,7-10 BAR-1 contatto SPDT -
  • Application:Provide control of steam, air, non-combustible gases or non-corrosive fluids
  • Operating Range: 1 to 8 psi
  • Mounting:1/4 in. NPT internal thread or surface mount through back of case
  • Switch Operation:Auto recycle
  • Switching Action:SPDT snap action, make R-W, break R-B on pressure rise
  • Sensor Element:Stainless Steel diaphragm
  • Pipe Connections, Main or High Pressure:1/4" NPT internal thread
  • Switch Contact Ratings (120v):8.0 AFL, 48.0 ALR, 10.0 A resistive
  • Switch Contact Ratings (240v): 5.1 AFL, 30.6 ALR, 5.0 A resistive
  • Maximum Sustained Operating Pressure: 25 psi
  • Pressure Differential (psi): 2 to 6 psi
  • Differential Type: Subtractive
  • Temperature Range: -35 to 150 F
  • Electrical Connections:Screw terminals
