MP953D5025 ATTUATORE PNEUMATICO 20mm 254retracts 120°

SKU: MP953D5025 Category:

MP953D5025 ATTUATORE PNEUMATICO 20mm 254retracts 120°

CONTATTACI PER RICHIEDERE IL PREZZO
Description

MP953D5025 ATTUATORE PNEUMATICO 20mm 254retracts 120°

Pneumatic actuator for valves in heating and air conditioning systems.
Actuators are suitable for valve series: V5011, V5013, V5015, V5049, V5050, V5016, V5025, V5328, V5329.
Protection class: IP54
Action: direct or reverse acting
Max. operating pressure: 140kPa
Rolling diaphragm
Max. safe air pressure: 172kPa

20 mm
Adjustable start point: no
Positioner: no
Stroke: 20mm
Effective diaphragm area: 254cm2
Action actuator stem: retracts
Max. ambient temperature: 120C
Pressure range: 27.6…75.9kPa

DESCRIZIONE PRODOTTO

MP953D5025 ATTUATORE PNEUMATICO 20mm 254retracts 120° Pneumatic actuator for valves in heating and air conditioning systems. Actuators are suitable for valve series: V5011, V5013, V5015, V5049, V5050, V5016, V5025, V5328, V5329. Protection class: IP54 Action: direct or reverse acting Max. operating pressure: 140kPa Rolling diaphragm Max. safe air pressure: 172kPa 20 mm Adjustable start point: no Positioner: no Stroke: 20mm Effective diaphragm area: 254cm2 Action actuator stem: retracts Max. ambient temperature: 120C Pressure range: 27.6...75.9kPa
